External Flows Applications

With Shape, you will enhance the possibilities of your external aero simulation chain, and get the most out of your flow data.

Request a Demo
About

NC SHAPE APPLICATION IN EXTERNAL FLOWS

Since many operating conditions need to be ran to get a full understanding of the drag and lift of a vehicle, companies in the automotive and aerospace sector generate hundreds of thousands of hours of CFD calculations.

Since many operating conditions need to be run to get a full understanding of the aerodynamic behavior of a vehicle, companies in the automotive and aerospace sectors generate innumerable hours of CFD calculations.

Most of these results are only looked at once and never used again. Since there is no reason to make the same mistake twice, Shape will learn from your heterogenous Computational Fluid Dynamics (CFD) data overnight.
Predict hundreds of results in a few sceonds

PREDICT HUNDREDS OF RESULTS IN A FEW SECONDS

While most engineers usually analyze only a few operating conditions, Shape makes it possible to predict hundreds of results in a few seconds, spanning a range of flow velocities or angles.

This can be predicted for a new design, provided actual simulation data on only a few operating conditions, or with no new simulation at all.

Learn more
NCS visualization in software
Predict both scalar and vector quantities in 3d

PREDICT BOTH SCALAR AND VECTOR QUANTITIES
Simulation
Prediction (R2 = 95%)

With Shape, you can predict not only integrated scalar quantities such as lift and drag, but also pressures and velocities on surfaces, slices, or directly in 3D.

Learn more

The Geometric Neural Networks used in Shape are particularly good at reproducing strong non-linearities, such as those induced by shock-waves or turbulent flows.

Explore and Compare Concepts

UNRESTRICTED EXPLORATION OF CONCEPTS

With Shape, you can gather data from different design exploration campaigns and naturally explore and compare concepts.

Your ideas and your history are not restricted by parameters

Ask a Specialist
Exploit Your DATA using Transfer learning techniques


COMPLEMENT YOUR CFD WITH PHYSICAL MEASUREMENT

Shape allows you to exploit your wind tunnel data in the best possible way.

Using transfer learning techniques, you can complement your CFD with physical measurement.

Read more
Compatible with your everyday tools


COMPATIBLE WITH YOUR EVERYDAY TOOLS
Shape is easily integrated with StarCCM+, Fluent, Openfoam, OMNIS and Paraview.
